FL-812/881 - Machined Sprockets
| No. of Teeth |
Outside Dia |
Pitch Dia |
Inside Dia |
| 17 |
104.0mm |
T104.2mm |
25-40mm |
| 19 |
117.0mm |
117.3mm |
25-40mm |
| 21 |
129.2mm |
130.0mm |
25-40mm |
| 25 |
153.2mm |
154.2mm |
25-40mm |
FL-802 - Machined Sprockets
| No. of Teeth |
Outside Dia |
Pitch Dia |
Inside Dia |
| 21 |
129.2mm |
130.0mm |
25-40mm |
| 25 |
153.2mm |
154.2mm |
25-40mm |
FL-812/881M – Molded Split Sprockets
| No. of Teeth |
Outside Dia |
Pitch Dia |
Inside Dia |
| 19 |
117.0mm |
117.3mm |
25-40mm |
| 21 |
129.2mm |
130.0mm |
25-40mm |
| 23 |
142.0mm |
142.3mm |
25-40mm |
| 25 |
153.2mm |
154.2mm |
25-40mm |
FL-881T – Molded Split Sprockets
| No. of Teeth |
Outside Dia |
Pitch Dia |
Inside Dia |
| 19 |
117.0mm |
117.3mm |
25-40mm |
| 21 |
129.2mm |
130.0mm |
25-40mm |
| 25 |
153.2mm |
154.2mm |
25-40mm |
FL-881T – Machined Sprockets
| No. of Teeth |
Outside Dia |
Pitch Dia |
Inside Dia |
| 19 |
117.0mm |
117.3mm |
25-40mm |
| 21 |
129.2mm |
130.0mm |
25-40mm |
| 25 |
153.2mm |
154.2mm |
25-40mm |
FL-820 – Machined Sprockets
| No. of Teeth |
Outside Dia |
Pitch Dia |
Inside Dia |
| 19 |
117.0mm |
117.3mm |
25-40mm |
| 21 |
129.2mm |
130.0mm |
25-40mm |
| 25 |
153.2mm |
154.2mm |
25-40mm |
FL-812/881M – Molded Split Sprockets
| No. of Teeth |
Outside Dia |
Pitch Dia |
Inside Dia |
| 19 |
117.0mm |
117.3mm |
25-40mm |
| 21 |
129.2mm |
130.0mm |
25-40mm |
| 23 |
142.0mm |
142.3mm |
25-40mm |
| 25 |
153.2mm |
154.2mm |
25-40mm |
FL-821 - Machined Sprockets
| No. of Teeth |
Outside Dia |
Pitch Dia |
Inside Dia |
| 21 |
129.2mm |
130.0mm |
25-40mm |
| 25 |
153.2mm |
154.2mm |
25-40mm |
FL-880T - Molded Split Sprockets
| No. of Teeth |
Outside Dia |
Pitch Dia |
Inside Dia |
| 10 |
122.5mm |
123.3mm |
25-40mm |
| 11 |
135.0mm |
135.5mm |
25-40mm |
| 12 |
147.0mm |
147.3mm |
25-40mm |
| No. of Teeth |
Pitch Dia |
Inside Dia |
| 8 |
122mm |
40mm |
| 10 |
149mm |
40mm |
FL-900 Flat Top/ Flushgid Sprockets
| No. of Teeth |
Pitch Dia |
Inside Dia |
| 10 |
89mm |
35-45mm |
| 12 |
104mm |
35-40mm |
| 15 |
130mm |
35-50mm |
| 18 |
155mm |
30-60mm |
| 20 |
173mm |
35-60mm |
| No. of Teeth |
Pitch Dia |
Inside Dia |
| 12 |
98mm |
30-50mm |
| 16 |
132mm |
30-50mm |
| 18 |
146mm |
30-65mm |
| 20 |
165mm |
30-65mm |
| No. of Teeth |
Pitch Dia |
Inside Dia |
| 32 |
157mm |
40mm |
| No. of Teeth |
Pitch Dia |
Inside Dia |
| 12 |
99mm |
40mm |
| 16 |
130mm |
40-50mm |
| 21 |
170mm |
40-50mm |
| 31 |
251mm |
40-60mm |
| No. of Teeth |
Pitch Dia |
Inside Dia |
| 12T |
58.1mm |
20-25mm |
| 16T |
77.7mm |
25-30mm |
| 24T |
115.5mm |
25-35mm |
| 32T |
154.8mm |
30-45mm |
| 38T |
166.7mm |
30-50mm |
| No. of Teeth |
Pitch Dia |
Inside Dia |
| 8T |
130mm |
25-50mm |
| 10T |
160mm |
25-50mm |
| No. of Teeth |
Pitch Dia |
Inside Dia |
| 10T |
81mm |
40-50mm |
| 12T |
97mm |
40-50mm |
| 15T |
121mm |
50-60mm |
| 18T |
145.1mm |
50-60mm |
| 19T |
153.1mm |
50-60mm |
