We are Global supplier of POM slat chains and we supply a wide range of POM chains at best cost with World class Quality.Superior Quality material is used in Manufacturing Process. These are used in Pulp industries, Tetra-pack industries, etc.,We are also supplying un-standard Tailor-made size chains globally based on the Quantity*
| Part No | Material | Thickness | Pitch | Color | Pin Material | Breaking Load | Width | Weight | |
|---|---|---|---|---|---|---|---|---|---|
| mm | mm | N | mm | inch | Kg/Mtr | ||||
| LF820K250 | POM | 4 | 38.1 | Brown | SS340 | 5.00 | 63.50 | 2 1/2 | 0.79 |
| LF820K325 | 5.00 | 82.50 | 3 1/4 | 0.85 | |||||
| LF820K400 | 5.00 | 101.60 | 4 | 0.95 | |||||
| LF820K450 | 5.00 | 114.30 | 4 1/2 | 1.03 | |||||
| LF820K600 | 5.00 | 152.40 | 6 | 1.25 | |||||
| Part No | Material | Thickness | Pitch | Color | Pin Material | Breaking Load | Width | Weight | |
|---|---|---|---|---|---|---|---|---|---|
| mm | mm | N | mm | inch | Kg/Mtr | ||||
| LF821K750 | POM | 4.8 | 38.1 | Brown | SS340 | 5.00 | 190.50 | 7 1/4 | 1.46 |
| LF821K1000 | 5.00 | 254.00 | 10 | 1.67 | |||||
| LF821K1200 | 5.00 | 304.80 | 12 | 1.95 | |||||
| Part No | Material | Thickness | Pitch | Min- Radius | Color | Pin Material | Breaking Load | Width | Weight | |
|---|---|---|---|---|---|---|---|---|---|---|
| mm | mm | mm | N | mm | inch | Kg/Mtr | ||||
| LF880T325 | POM | 4 | 38.1 | 500 | Brown | SS340 | 5.00 | 82.50 | 3 1/4 | 0.85 |
| LF880T450 | 5.00 | 114.30 | 4 1/2 | 1.03 | ||||||
| LF880T750 | 5.00 | 190.50 | 7 1/2 | 1.46 | ||||||
| Part No | Material | Thickness | Pitch | Min- Radius | Color | Pin Material | Breaking Load | Width | Weight | |
|---|---|---|---|---|---|---|---|---|---|---|
| mm | mm | mm | N | mm | inch | Kg/Mtr | ||||
| LF880T325 | POM | 4 | 38.1 | 500 | Brown | SS340 | 5.00 | 82.50 | 3 1/4 | 0.85 |
| LF880T450 | 5.00 | 114.30 | 4 1/2 | 1.03 | ||||||
| LF880T750 | 5.00 | 190.50 | 7 1/2 | 1.46 | ||||||
